Manufacturer Specification
Display Type: TFT LCD Technology
Model: UC46(Built-in Anycast)
Resolution: 800x480
Compatible Resolution: 800x600; 1024x768,1280x800,1920x1080
Brightness: 1200 Lumens
Contrast: 800:1
Aspect Ratio: 4:3 ,16:9
Projection Method: Front/Rear/Suspended Ceiling Projection
Keystone Correction: +/- 15 Degrees
Focusing Manner: Manual Focus
Image Size: 34 to 130 Inches
Projection Distance: 1.07-3.8M
Lamp: LED Lamp
Power : 55W Max
Speakers: 8Ω2W
System : UNi-Link OS
Wireless : WIFI 2.4G Anycast
Lamp Life: Estimated life of over 20,000 Hours
Others
Audio Format: MP3, WMA ,ASF, OGG,AAC,WAV
Video Format: 3GP(H263,MPEG4)/AVI(XVID,DIVX,H264)/MKV(XVID,DIVX,H264)/FLV(FLV1)/MOV(H264)/MP4(MPEG4,AVC)/MPG(MPEG1)/VOB(MPEG2)/RMVB(RV40)
Image Format: JPEG, BMP, PNG
Document : TXT
Power Requirement: 100 to 240V AC, 50/60HZ
Interfaces
DC In
2 x USB Port
HDMI
AV IN
Earphone jack
VGA
Dimensions
Operation:
1.VAG Input:
Choose PC-RGB input, and connect project with VGA device
Switch to projection by computer: Win 7 system press Fn plus P, other system press Fn plus F and the asterisk key
While working, 5V out can use to charge cellphone or tablet
2.Wireless Display:
Wireless function support MIRACAST Protocol and other popular wireless connection
Select Wireless Display source and press OK enter Uni-Link page
If you see SSID: UNi-Link-1E000CE, then go to operate your device
If you use Android device, please confirm your device can support WIFI DISPLAY
More details instruction please kindly to check user manual
3.How to use DLNA:
Press OK button on remote or keypad to switch to DLNA mode
Connect your mobile to Uni-Link-XXXXXXX, then you can push multimedia content from your mobile to projector
